Mounted 360°Full Rotation Integrated Machine
CY-360-M12
The mounted 360°fully rotating integrated machine has a rated power of 10-30kW and is suitable for small ships within 12 meters. It is used in cultural tourism, fishing boats, transportation boats, competitive boats and other scenarios.
Product Specifications
Product Information
Product Name
Mounted 360°Full Rotation Integrated Machine
Product Model
CY-360-M12
rated power
10-30kW
Applicable ship types
Small vessels within 12 meters
Application Scenarios
Cultural tourism sightseeing,fishing boats,transportation boats,competitive boats
Core parameters
rotation speed
1500rpm
Propeller diameter
300mm
steering angle
360°full rotation
thrust
Maximum 120kgf
efficiency
≥92%
Installation Method
Stern-mounted
Control method
wire control
response time
<100ms
salt spray rating
C5-M
Other parameters
Core Highlights
360°full rotation, easy installation, zero emissions, low noise
Motor type
Permanent magnet synchronous motor
Rated Voltage
DC 48V/96V
Cooling method
Natural Water Cooling
Protection rating
IP67
System Weight
45-65kg
Noise level
<60dB
Battery parameters
Lithium iron phosphate battery (optional)
Charging time
Fast charging for 2 hours/slow charging for 6 hours
Operating temperature
-10℃-55℃
Certification standard
CCS certification, ISO9001
Design life
30,000 hours
