Built-in all-in-one machine
CY-IN-75-500
The built-in integrated machine, with a rated power ranging from 75 to 500 kW, is suitable for medium to large vessels exceeding 20 meters in length, and can be applied to scenarios such as 20-meter yachts, fishery transport ships, and tugboats.
Product Specifications
Product Information
Product Name
Built-in all-in-one machine
Product Model
CY-IN-75-500
rated power
75-500kW
Applicable ship types
Medium and large-sized ships over 20 meters
Application Scenarios
20-meter yacht, fishery transport vessel, tugboat
Core parameters
Rated speed
1600rpm
Peak torque
3200N·m
efficiency
94% (rated point 96%)
propeller
4-blade fixed-pitch propeller
Material
Nickel aluminum bronze Cu3
insulation class
H-level
Control method
Variable frequency vector control
monitoring system
Real-time monitoring of temperature, vibration, and rotational speed
Other parameters
Core Highlights
High power output, high reliability, low maintenance cost, intelligent monitoring
Motor type
Permanent magnet synchronous motor (PMSM)
Rated Voltage
AC 380V/690V
Cooling method
Forced water cooling
Protection rating
IP68
System Weight
350-1200kg
Noise level
<75dB
Battery parameters
Lithium iron phosphate battery pack (optional)
Charging time
Fast charging 1.5 hours/slow charging 5 hours
Operating temperature
-20℃-60℃
Certification standard
CCS, DNV, ABS cert
Design life
50,000 hours
